Compost Processing Trommel Screen with Circular Design and Feeding Size less than 300mm

Product Categories
Zhengzhou Sinolion Machinery Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Compost Processing Trommel Screen with Circular Design and Feeding Size less than 300mm

Applicable Industries : Building Material Shops, Construction works , Energy & Mining

Showroom Location : Mexico

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : New Product 2020

Warranty of core components : 1 Year

Core Components : Motor

Condition : New

Type : Circular

Application : Ore, compost, waste, bark, MSW, building waste, construction waste

Place of Origin : Henan, China

Brand Name : sinolion

Voltage : 380v/415v/440v

Dimension(L*W*H) : depends on processing Trommel Screen

Weight : KG

Warranty : 1 Year

Product name : Efficient Compost Processing Trommel Screen For Sale

Screen material : steel bar, steel plate punch hole, steel wire woven, stainless steel

Power : 3-45KW

Dimension : according to capacity

Installation : supply manual to guide user

Capacity : 50-500 tons per hour

Feeding size : less than 300mm

Discharge size : as request

Color : yellow, white, red, blue, gray( or as client request)

Price : $1,500.00/sets >=1 sets

MOQ : 1 unit

Contact Now

Product Description

Product Application

Compost trommel screen is a special screening equipment specially developed by our company for power plants, heat companies, mining, chemical, building materials and coking industries. It is especially suitable for screening coal, coke, white ash and other wet and easy to block materials. The device overcomes the problem of screen clogging which occurs when the circular vibrating screen and the linear vibrating screen filter the wet materials, improves the output of the system and enhances the reliability, and is highly praised by the users.

Working principle

Compost trommel screen has a simple structure and is mainly composed of a motor, a speed reducer, a roller device, a frame and the like. The circular roller device is mounted obliquely on the frame, and the motor is connected to the roller device through the coupling via the reducer. When the material enters the circular drum, the circular drum rotates under the action of the motor, and the material moves in the cylinder with the rotation direction of the drum. The size of the screen mesh installed in the drum is different, and the materials of different grain sizes gradually rotate with the drum. It is separated by screening, and the final finished material is discharged from the discharge port below the drum to complete the screening work.


Detailed images
Compost Processing Trommel Screen with Circular Design and Feeding Size less than 300mm
Technical Prameter
Model
Capacity
(t/h)
Power
(kw)
Diameter
(mm)
Length
(mm)
Discharge
(mm)
Input
(mm)
Dimension
(mm)
GTS1015
50
3.0
1000
1500
0-100
≤300
2600×1400×1700
GTS1020
100
4.0
1000
2000
0-100
≤300
3390×1400×2140
GTS1225
160
5.5
1200
2500
0-100
≤300
4146×1600×2680
GTS1530
250
7.5
1500
3000
0-100
≤300
4460×1900×2820
GTS1545
350
11
1500
4500
0-100
≤400
5960×1900×3080
GTS1848
450
15
1800
4800
0-100
≤400
6500×2350×4000
GTS2055
600
22
2000
5500
0-100
≤400
7500×2550×4800
GTS2265
800
30
2200
6500
0-100
≤400
8500×2750×5000

Design and produce compost trommel screen based on customer special requirement

Company Information

ABOUT US

Zhengzhou Sinolion Mxchinery Co., Ltd. is a high-tech Company which professional manufacturing the production of briquette equipment, screening equipment and mining machinery. Sinolion has continuously improved product values and performance. Sinolion products have been exported to Serbia, The United Kingdom, Poland, Turkey, Malaysia, Indonesia, Kazakhstan,Vietnam, North Korea, Egypt, Mexico, Ghana, Cameroon, Tanzania, Migeria, South Africa, Bolivia, Canada and other countries and regions.

We will continue to adhere to "Quality is our eternal pursuit and pride", creat new glories with customers! Welcome to SINOLION for visiting and seeking common development.

Compost Processing Trommel Screen with Circular Design and Feeding Size less than 300mm
Compost Processing Trommel Screen with Circular Design and Feeding Size less than 300mm
Our Service

Our company not only has superb technical staff and experienced after-sales service team,but also keeps in step with the times. Bring internet technology into all aspects of production and operation, goes in for internet marketing actively, offers latest product information and technical service.

Compost Processing Trommel Screen with Circular Design and Feeding Size less than 300mm

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

Compost Processing Trommel Screen with Circular Design and Feeding Size less than 300mm

In-Sales

* Strict inspection before leaving factory.

* Delivery goods according to contract

Compost Processing Trommel Screen with Circular Design and Feeding Size less than 300mm

After-Sales Service

* Training how to instal compost trommel screen, training how to use the machine.
* Engineers available to service machinery overseas.

Packing & Delivery
Compost Processing Trommel Screen with Circular Design and Feeding Size less than 300mm
Packaging
Model GTS1548 trommel screen packing method
Size
8500mm (L) * 22500mm (W) * 2450mm (H)
Weight
8.6 T



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries, the wooden box will be fumigated.If equipment is too bigger, we will use 20GP or 40GP or 40HQ which is according to customers special request.
Compost Processing Trommel Screen with Circular Design and Feeding Size less than 300mm
Packaging
Other large models of compost trommel screen
Size
8900mm (L) * 2430mm (W) * 2500mm (H)
Weight
7.2 T



Packaging Details


This machine can not goes into container, we use flat container for shipment, package with film.
FAQ

How do I choose a suitable compost trommel screen?

In your first inquiry, please let us know your information and requirements, we will give you guidance for choosing the right machine.

Can we visit your factory and use your equipment do the test?

Yes. Our technician can do the test for you and you can see the whole working principle clearly.

What's the delivery time after I pay the deposit?

We will clear delivery time in slaes contract, Single compost trommel screen machine often deliveried within 10-15 working days after receipt of the pre-payment. Complete production line will delivery within 25-40 working days after receipt of the pre-payment.

How long of your compost trommel screen machine quality guarantee terms?

Quality guarantee time is one year(wearing parts excluded).
